{{ labels['key-features'] }}
-
{{ featureCallout.Title }}
Wattage
Multi-Watt™ 50 or 100 (Channel Assignable)
Channels & Modes
3 Channels / 8 Modes
Mode Voicings styles
Ch. 1 = Clean or Pushed Ch. 2 = Raw, Vintage High Gain or Modern High Gain Ch. 3 = Raw, Vintage High Gain or Modern High Gain
Graphic Eq Reverb Fx Solo
FX Loop, Solo
Foot switchable Functions
Ch. 1, 2, 3, Mute, FX Loop, & Solo
Speakers Impedance
n/a
Weight
41 Lbs.
Dimensions
10" H x 25 1/2" W x 9 7/8" D
Available Formats
Head
Amp Type
Tube
Rectifier Type
Selectable and Channel Assignable Dual Rectification (Tube or Silicon Diodes) with Patented Recto Tracking™ (Patent 7,193,458). Recto Tracking™ auto-matches the correct Rectifier compliment for the number of Power Tubes in use.
Rectifier Tubes
2x Mesa 5U4
Variac PowerSwitch
Bold/Spongy Power Switch
Preamp Tubes
5x Mesa 12AX7
Power Amp Tubes
4x Mesa 6L6 (or EL-34)
Maintenance Free Fixed Bias
Yes
Wattages Quick Reference
50 or 100 Watts - Channel Assignable - See Power Amp Details for more information
Built In Power Amp Attenuation
n/a
Power Amp Details Class Wattage
Class A/B Power with Mesa's patented Multi-Watt™ Channel Assignable Power Amp (Patent 7,602,927) - Provides two power options that are channel assignable via three 50/100 Watt Power Switches: Choose 2 power tubes, producing 50 Watt of small block-power or all 4 power tubes producing 100 Watts of big-block horsepower and authority.
Number Of Style Modes
Eight
Number Of Style Modes Per Channel
Channel 1 = Two Channel 2 & 3 = Three
Channel Controls
Each Channel features Independent Style Mode Switch, 50/100 Multi-Watt™ Switch, Gain, Treble, Mid, Bass, Presence, Master, Assignable Dual Rectification with Recto Tracking™ (Diode or Tube - Patent 7,193,458)
Graphic Eq And/or Contour
n/a
Reverb Effects Bypass Options
n/a
Effects Loop Bypass Options
Fully Buffered Series FX Loop w/Send Level Control - Footswitchable, Channel Assignable or True Bypassable - See True-Bypass Options below for more information
Global Output Level Control
Yes (Over all channels when activated) - See True-Bypass Options below for more information
Global Solo Level Control
Yes (Over each channel when activated) - See True-Bypass Options below for more information
True Bypass Options
True-Bypass Switch removes FX Loop, Output & Solo Level Controls
External Switching Jack Options And/or Midi
External Switching Jacks for Channels 2, 3 (Ch. 1 is default), FX Loop & Solo
Speaker Outputs
One 16 Ohm, Two 8 Ohm & Two 4 Ohm
Cabinet Simulation Direct Live recording Output
n/a
Internal Amp Load For SpeakerLess Performance
n/a
Headphone Output
n/a
Slave Output
Yes, with Level Control
Extra Features
n/a
Footswitch
Included - 3x3 - 6 Button Footswitch (Bottom Row: Ch. 1, Ch. 2 & Ch. 3 - Top Row: Tuner Mute, FX Loop & Solo)
Slip Cover
Included - Fitted Slip Cover
Cabinet Material
Marine Grade, Baltic Birch
Standard Finish Options (no extra cost)
Antique Red King Crocodile leather, matching Antique Red King Crocodile leather Front Panel with custom Black Vents (front and top), Black Piping, Black Rubber Handle with matching Black Handle Caps, Black Leather Corners, and custom Black Knurled knobs
Custom Finish Options
n/a
Speakers Impedance
n/a
Casters
n/a
Extra Features
Custom Configured: Antique Red King Crocodile leather, matching Antique Red King Crocodile leather Front Panel with custom Black Vents (front and top), Black Piping, Black Rubber Handle with matching Black Handle Caps, Black Leather Corners, and custom Black Knurled knobs
Weight
41 Lbs.
Height
10"
Width
25 1/2"
Depth
9 7/8"
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
