{{ labels['key-features'] }}
-
{{ featureCallout.Title }}
Wattage
25 or 10 Watt Selectable (Global)
Channels & Modes
2 Channels / 3 Mode Channel Cloning™
Mode Voicings styles
2 Channels / 3 Mode Channel Cloning™
Graphic Eq Reverb Fx Solo
FX Loop
Foot switchable Functions
Ch. 1/2
Speakers Impedance
n/a
Weight
19 lb. / 8.62 kg.
Dimensions
8 1/2" H x 18 3/8" W x 10" D / 21.59 cm H x 46.67 cm W x 25.40 cm D
Available Formats
Head & 1x12 Combo
Amp Type
Tube
Rectifier Type
Silicon Diodes
Rectifier Tubes
n/a
Variac PowerSwitch
n/a
Preamp Tubes
5x 12AX7
Power Amp Tubes
2x EL-84
Maintenance Free Fixed Bias
Yes
Wattages Quick Reference
25 or 10 Watt Selectable (Global)
Built In Power Amp Attenuation
n/a
Power Amp Details Class Wattage
Class A/B Power with global 25/10 Power Switch - Provides two power options: Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 10 Watts or 2 tubes operating in Mesa's proprietary Dyna-Watt™ Class A/B Pentode for maximum power, punch, and clarity, producing 25 Watts
Number Of Style Modes
Three
Number Of Style Modes Per Channel
Three (Channel Cloning™)
Channel Controls
Each Channel features Independent, 3-Position Style Mode Switch, Gain, Treble, Mid, Bass, Presence, Master, and 8-Position CabClone IR Select (back-panel) Controls
Graphic Eq And/or Contour
n/a
Reverb Effects Bypass Options
n/a
Effects Loop Bypass Options
Tube-Driven, Series FX Loop
Global Output Level Control
n/a
Global Solo Level Control
n/a
True Bypass Options
n/a
External Switching Jack Options And/or Midi
n/a
Speaker Outputs
One 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output
Built-in, channel assignable, MESA CabClone™ IR Cab Simulator featuring 8 MESA Cabinet IRs, USB Connection for IR transfers, Internal Amp Load for cabinet-free use, IR Balanced XLR Direct Output, Headphone Output, IR Output Level Control, & Ground/Lift Switch
Internal Amp Load For SpeakerLess Performance
Yes (see Cabinet Simulation for more information)
Headphone Output
Yes (see Cabinet Simulation for more information)
Slave Output
n/a
Extra Features
n/a
Footswitch
Included - 1 Button Footswitch (Ch. 1/2)
Slip Cover
Included - Fitted Slipcover
Cabinet Material
Marine Grade, Baltic Birch
Standard Finish Options (no extra cost)
Black Bronco Vinyl, Black Diamond Plate, Black Handle & Corners
Custom Finish Options
See Custom Finish Gallery
Speakers Impedance
n/a
Casters
n/a
Extra Features
n/a
Weight
19 lb. / 8.62 kg.
Height
8 1/2" / 21.59 cm
Width
18 3/8" / 46.67 cm
Depth
10" / 25.40 cm
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
