{{ labels['key-features'] }}
-
{{ featureCallout.Title }}
Wattage
Multi-Watt™ 1, 10, or 20
Channels & Modes
1 Channel
Mode Voicings styles
Single Channel with two Inputs: Normal Input = Clean to Overdrive Low Input = Clean
Graphic Eq Reverb Fx Solo
Reverb
Foot switchable Functions
Reverb (Footswitch & Cable sold seperately)
Speakers Impedance
1 - 8 Ohm Jensen Blackbird Alnico 40 / Total Load = 8 Ohms
Weight
36.6 Lbs.
Dimensions
18" H x 18 1/2" W x 10" D
Available Formats
Head, 1x10, & 1x12 Combo
Amp Type
Tube
Rectifier Type
Silicon Diodes
Rectifier Tubes
n/a
Variac PowerSwitch
n/a
Preamp Tubes
5x Mesa 12AX7 & 1x Mesa 12AT7
Power Amp Tubes
2x Mesa 6V6
Maintenance Free Fixed Bias
Fixed Bias (20- & 10-Watt Modes) & Cathode Bias (2-Watt Mode) both provide consistent, maintenance-free performance
Wattages Quick Reference
1, 10, or 20 Watts - See Power Amp Details for more information
Built In Power Amp Attenuation
n/a
Power Amp Details Class Wattage
Mesa's Patented Incremental Multi-Watt™ (Patent 9,917,560) Power Amp, featuring Duo-Class™ (Patent 7,173,488) and Dyna-Watt technologies, provides three power, two operating-classes and three wiring configuration options via one 3-Way Power Switch - Choose from the following power options: 20 Watts - 2x6V6 Class A/B Pentode – Fixed Bias 10 Watts - 2x6V6 Class A/B Triode – Fixed Bias 1 Watt - 1x6V6 Pentode, Single-Ended Class A – Cathode Bias -More information on Dyna-Watt Power can be found in the Owners Manual, which is available in the Support Section of this website.
Number Of Style Modes
Two (Inputs)
Number Of Style Modes Per Channel
Two (Inputs)
Channel Controls
Gain, Treble, Mid, Bass, Presence, Reverb, and Master
Graphic Eq And/or Contour
n/a
Reverb Effects Bypass Options
All-Tube, Spring Reverb
Effects Loop Bypass Options
Fully Buffered Series FX Loop
Global Output Level Control
n/a
Global Solo Level Control
n/a
True Bypass Options
n/a
External Switching Jack Options And/or Midi
External Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold separately)
Speaker Outputs
One 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output
n/a
Internal Amp Load For SpeakerLess Performance
n/a
Headphone Output
n/a
Slave Output
n/a
Extra Features
n/a
Footswitch
Optional - 1 Button Footswitch (Reverb) & Cable (Sold Separately)
Slip Cover
Included - Fitted Slip Cover
Cabinet Material
Marine Grade, Baltic Birch
Standard Finish Options (no extra cost)
Choice of Cream Bronco Vinyl, Cream/Tan Weave Jute Grille, Brown Handle & Corners or Black Bronco or Black Taurus Vinyl, Black Jute Grille, Black Handle & Corners
Custom Finish Options
See Custom Finish Gallery
Speakers Impedance
1 - 8 Ohm Jensen Blackbird Alnico 40 / Total Load = 8 Ohms
Casters
Optional - Track-Loc™ Removable Casters
Extra Features
Vintage-Inspired Construction for Tone & Portability
Weight
36.6 Lbs.
Height
18"
Width
18 1/2"
Depth
10"
Disclaimer: In order to continually improve the design, quality and performance of our products and to use the best materials at all times, MESA/Boogie reserves the right to substitute or change specifications (including parts or coatings) without notice.
